Ultra-Pure® CPVC
Light Weight and Corrosion-Resistant Pipe for Potable Water Distribution
Ultra-Pure® CPVC does not corrode or accumulate mineral deposits. It may be used for the distribution of potable water in the United States and where approved by Authorities Having Jurisdiction.
Ultra-Pure® CPVC meets the 25/50 flame spread and smoke development requirement for plenum applications. Ref: ICC-ES PMG-1323 in general accordance with ASTM E 84.
Tough Pipes that Meet Tough Standards
Ultra-Pure® CPVC pipe is made with CPVC 4120 (Type IV, Grade I) resin having a cell classification of 24448 per ASTM D1784. The maximum service temperature for Ultra-Pure CPVC is 180°F (82°C), at 100psi.
Meets the requirements of FHA Use of Materials Bulletin 76.
Ultra-Pure is offered 1/2” through 2” CTS SDR-11 (Copper Tube Size).
top resources
Learn more about Ultra-Pure® CPVC
Our resources section covers everything you need to know about Ultra-Pure® CPVC. Take a look at our most popular resources below
Specifications
CPVC 4120 (Type IV, Grade I) resin
½ – 2” (13 – 51 mm)
400 PSI (2758 kPa) Working Pressure at 73°F (23°C)
100 PSI (690 kPa) Working Pressure at 180°F (82°C)
ASTM D2846
NSF listed and complies with Standard 14 and 61
Potable Water
